Dispersion
Reactors
S & S Industries proudly introduces its advanced range of Chemical Reactors, designed for efficient, safe, and controlled processing across diverse industries. Our reactors are engineered with precision to deliver consistent performance in complex chemical reactions involving liquids, gases, and solids.
What is a Chemical Reactor?
A chemical reactor is a process vessel designed to carry out chemical reactions under controlled conditions such as temperature, pressure,
and mixing.
At S & S Industries, our reactors are:
- Cylindrical vessels with optimized geometry
- Equipped with efficient agitation systems
- Designed for uniform heat transfer
- Built for high safety and operational reliability
They enable precise control over reaction parameters, ensuring improved product quality and process efficiency.
Efficient Mixing & Superior Dispersion
Our high-speed dispersers feature an open disc blade that operates at speeds of up to 5,000 feet per minute, creating powerful turbulent flow within low-viscosity batches. This process forms a vortex that allows for the quick incorporation of dry ingredients, ensuring fast and uniform wetting.
Optimized Performance & Versatility
To maintain a consistent vortex and efficient material turnover, the blade speed can be adjusted as the batch thickens or increases in volume. Additionally, to prevent stratification or layering, most models are designed with an adjustable height mechanism, allowing the disperser to be raised or lowered during the mixing process.
Key Applications
Our chemical reactors are widely used for:
- Acid and solvent processing
- Polymerization and condensation reactions
- Mixing and blending of chemicals
- Heating and cooling operations
- Synthesis of organic and inorganic compounds
Importance of Chemical Reactors
Chemical reactors play a critical role in industrial processing by:
- Ensuring controlled and safe reactions
- Enhancing reaction efficiency and yield
- Providing uniform mixing and heat transfer
- Supporting scalable production
- Maintaining product consistency
Design Features
Robust Construction
- Available in SS 304 / SS 316 / Mild Steel / Alloy Steel
- Corrosion-resistant and long service life
Efficient Agitation System
- Propeller / Turbine / Anchor type agitators
- Custom-designed based on process requirement
Heating & Cooling System
- Jacketed or limpet coil design
- Compatible with steam, thermic fluid, or chilled water Pressure & Temperature Control
- Designed for atmospheric and pressurized operations
- Integrated control systems for precision
Safety & Compliance
- Designed as per industrial standards
- Provision for safety valves, pressure gauges, and sensors
Technical Specifications
| Model | Gross Capacity (L) | Working Capacity (L) | Shell Dimensions (mm) | Motor HP |
|---|---|---|---|---|
| SSR-25 L | 30 | 25 | Ø 300 x 400 HT | • As per S&S Industries Standard |
| SSR-50 L | 60 | 50 | Ø 380 x 480 HT | |
| SSR-100 L | 120 | 100 | Ø 500 x 650 HT | |
| SSR-250 L | 300 | 250 | Ø 650 x 900 HT | |
| SSR-500 L | 600 | 500 | Ø 800 x 1000 HT | |
| SSR– 0.5 KL | 600 | 500 | Ø 800 x 1000 HT | 0.6 |
| SSR – 1 KL | 1200 | 1000 | Ø 1060 x 1250 HT | 1.5 |
| SSR – 1.5 KL | 1800 | 1500 | Ø 1200 x 1500 HT | 2 |
| SSR – 2 KL | 2400 | 2000 | Ø 1300 x 1600 HT | 2.5 |
| SSR – 2.5 KL | 3000 | 2500 | Ø 1400 x 1800 HT | 3 |
Note: The data shown are indicative values and depend on the product being processed. Viscosity of the product directly variable to flow rate.
Tailor-Made Solutions
With our expertise, we cater to diverse and specialized project requirements by delivering tailored solutions—such as the Reactors—to meet your specific process needs.
Catalouge Download
Discover more about our Reactors in a compact PDF format—field-proven thousands of times for
